Four Point Contact Ball Slewing Bearing (No Gear)

PMK Four Point Contact Ball Slewing Bearings (No Gear) are designed to carry combined axial, radial, and moment loads within a minimal structural envelope. The four-point contact design allows bidirectional axial load support and smooth rotation under light torque.

Key benefits

Compact structure with high axial and radial load capacity.
Smooth, low-torque rotation and precise motion.
Four-point ball contact provides bidirectional thrust support.
Lightweight design suitable for precision applications.
Maintenance-free operation with sealed or greased options.

Applications

Robotics and automation systems.
Light-duty rotary tables and manipulators.
Medical and optical instruments.
Packaging and positioning equipment.

Request Quote (RFQ)

Specifications

Boundary dimensions (mm)			Mount dimensions (mm)						Structure dimensions (mm)						Basic load ratings (kN) Coa	Designations	Mass (kg)
d	D	H	D₁	D₂	n₁	n₂	φ1	φ2	D₃	d₁	H₁	h	n₃	φ3	Basic load ratings (kN) Coa	Designations	Mass (kg)
260	480	60	444	296	16	16	14	14	360	380	60	-	-	-	754	116752	55
460	590	45	570	488	8	12	M10	10	518	542	45	-	-	-	626	176792	35.9
	590	45	570	488	12	12	10	10	518	542	45	-	-	-	626	176792K	36
	590	45	570	488	12	8	10	10	526	534	45	-	-	-	944	176792K2M	30.8
530	780	60	740	560	20	20	17	13	645	665	35	-	-	-	1120	1167/530	103
560	720	36	690	590	12	12	14	12	638.5	641.5	33	3	-	-	708	1167/560	40.3
	720	36	690	590	12	32	M12	16	634	646	36	3	-	-	708	1167/560K	39.2
	720	36	690	590	12	12	14	12	638.5	641.5	36	3	-	-	708	1167/560M	38.1
700	900	36	860	740	12	12	M16	17	796	804	36	3	-	-	1790	1167/700	60
760	950	80	915	795	24	24	18	M16	853.5	856.5	71	9	4	M10×1	2030	E787/760G2	138
775	1000	64	948	802	24	12/12	M12	13/M12	878	882	49	15	2	M8×1	1960	3-640	112
800	1050	90	1012	838	30	30	20	20	923	927	76	16	3	M10×1	2150	787/800G	192
850	1120	85	1074	924	12	12	M20	22	995	1010	85	-	-	-	1510	71769/850Y	248
932	1200	120	1148	984	40	40	26	M24	1064	1068	100	20	4	G1/4in	3490	787/932G2	328
960	1165	90	1135	1040	36	36	18	M16	1073	1077	78	14	6	M10×1	2490	787/960G2	202
1000	1250	100	1206	1044	12	12	18	M16	1123	1127	90	10	3	M10×1	5400	787/1000G2	283
1260	1509	90	1465	1315	36	36	22	M20	1386	1389	70	14	2	ZG1/8in	3780	787/1260G2	274
1400	1820	136	1750	1470	24	24	35	35	1608	1612	136	-	4	M10×1	6110	71169/1400Y	1114
	1820	136	1750	1470	24	24	35	35	1608	1612	136	-	4	M10×1	10700	71169/1400Y1	1120
	1780	100	1730	1494	48	48	22	M20	1618	1622	85	15	4	M12×1.25	5030	787/1440G2	533
1628	1927	130	1875	1680	36	36	26	M24	1774	1778	115	15	6	G1/4in	6920	787/1628G2	732
1700	2000	150	1950	1750	24	24	21	21	1842	1858	130	20	4	M10×1	6840	787/1700KM	826
1825	2178	144	2110	1891	48	48	33	33	1998	2002	132	12	8	M10×1	12100	010.60.2000.**	1100
2065	2418	144	2350	2131	48	48	33	33	2237.5	2242.5	132	12	8	M10×1	13500	010.60.2240.**	1250
2325	2678	144	2610	2391	56	56	33	33	2497.5	2502.5	132	12	8	M10×1	15000	010.60.2500.**	1400
2625	2978	144	2910	2691	56	56	33	33	2797.5	2802.5	132	12	8	M10×1	16800	010.60.2800.**	1600
2922	3376	174	3286	3014	56	56	45	45	3147.5	3152.5	162	12	8	M10×1	23800	010.75.3150.**	2800
3322	3776	174	3686	3414	56	56	45	45	3547.5	3552.5	162	12	8	M10×1	26900	010.75.3550.**	3200
3772	4226	174	4136	3864	60	60	45	45	3997.5	4002.5	162	12	10	M10×1	30200	010.75.4000.**	3600
4272	4726	174	4636	4364	60	60	45	45	4497.5	4502.5	162	12	10	M10×1	34100	010.75.4500.**	4000
