The PSFE Series utilizes a compact internal return flange single nut design, optimized for high-performance motion control where space efficiency is a priority. This series integrates the recirculation system within the nut body, providing a smooth profile and reliable operation.

Featuring shaft diameters from 16 mm to 50 mm, the PSFE series delivers a strong balance of load capacity and mechanical stiffness. It offers a dynamic load rating of up to 6,768 Kgf, a static capacity of 21,260 Kgf, and a maximum rigidity of 121 Kg/µm. It is an excellent choice for modern CNC centers and automated storage systems.

Key benefits

• Compact Footprint: Internal return system allows for a streamlined nut design.
• High Efficiency: Optimized ball recirculation path reduces friction and improves torque performance.
• Precise Motion: Consistent accuracy for point-to-point applications.
• Flexible Configuration: Multiple lead and shaft diameter options for diverse motion tasks.

Applications

• Vertical machining centers (VMC) and high-speed CNC machinery.
• Automated storage and retrieval systems (AS/RS).
• Industrial robotics and automated material handling equipment.
• High-precision electronic component assembly machines.
